11.4.2 Overview - Distance Regulation Control Module - J428- "Master", Distance Regulation Control Module 2 - J850- "Slave"

NOTE: The Distance Regulation Control Module - J428- "Master" is shown in the illustration. The location of the components for the Distance Regulation Control Module - J428- "Slave" is a mirror image.

1. Nut
2. Stud Bolt
   • Replace the clip if the adjusting screw was removed.
   • Note the adjustment dimension when assembling
3. Clip
   • Replace the clip if the adjusting screw was removed.
   • Removing and installing. Refer to 11.4.4 Remove the Clip On the Distance Regulation Control Module - J428- "Master", Distance Regulation Control Module 2 - J850- "Slave"
4. Connector
5. Cover
6. Distance Regulation Control Module - J428-
   • Removing and installing. Refer to 11.4.3 Distance Regulation Control Module - J428-, Removing and Installing
7. Bracket
8. Bolt
   • 4.5 Nm
   • Quantity: 4
