Output Shaft Speed Sensor Removal and Installation: Installation

Reference:  OUTPUT SHAFT SPEED SENSOR INSPECTION

1. Apply A/T fluid to new output shaft speed sensor O-ring.
2. Install output shaft speed sensor (1) to A/T case and tighten bolt to specified torque.

   Tightening torque

   Output shaft speed sensor bolt a: 5.5 N.m (0.55 kg-m, 4.0 lb-ft)

3. Connect output shaft speed sensor connector (2) to output shaft speed sensor (1).
   Fig 1: Identifying Output Shaft Speed Sensor Connector

   Courtesy of SUZUKI OF AMERICA CORP.
4. Connect negative cable to battery.
