Digital Clock Installation

  1. Install the digital clock with the screws.

    Tighten

    Tighten the digital clock screws to 2.5 N.m (22 lb-in).

  2. Install the instrument cluster trim panel. Refer to "INSTRUMENT CLUSTER TRIM PANEL INSTALLATION ".
Fig 1: Installing Digital Clock With Screws
G04096151Courtesy of SUZUKI OF AMERICA CORP.
