Threaded Pins, Replacing

WARNING: This page is about a different car, the 2025 Audi S3, 2025 Audi RS 3, and 2025 Audi A3 Quattro. However, it is still accessible from the selected car via links, so may be relevant.

Replacing the weld screws, threaded pins, and weld pins with cap nut is described as an example.

Apply the procedures the same way for all types.

Fig 1: Ground Cable Location, And Welding Threaded Pins Using Gas-Shielded Arc Continuous Weld Seam

Courtesy of AUDI OF AMERICA, LLC

-- Transfer the installation position of the threaded pins from the used part or mark using for example the ground cable location -arrow-.

-- Weld the threaded pins with two opposite weld seams -1- with a Gas-Shielded Welder using a gas-shielded arc continuous weld seam.

To ensure sufficient electrical conductivity, the length of the weld seams on the threaded pin must be at least 12 mm on each side.

-- Clean the contact surface on the threaded pin after completing the welding work.
