Engine/Motor Control Module, Relay And Fuse Panel 1

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

J359

Low Heat Output Relay

J623

Engine/Motor Control Module Type:BT, Slpdok:, Aim:BTJ623

SR1

Relay and Fuse Panel 1

T94a

94-Pin Connector, Black Type:VA, Slpdok:, Aim:VAT94a

*

Refer to Applicable Wiring Diagram for Fuses in Engine/Motor Compartment

*2

For Vehicles with Auxiliary Heater

*3

Through July 2022

*4

From July 2022
