Component Location Overview - Electrical Components, Transmission Control
WARNING: This page is about a different variant/trim than selected.
- Dual-Clutch Transmission Mechatronic -J743-
- Removing and Installing. Refer to MECHATRONIC, REMOVING AND INSTALLING .
- Not for this model
- Selector Lever -E313-
- With Selector Lever Sensor System Control Module -J587-, Shift Lock Solenoid -N110- and Selector Lever Park Position Lock Switch -F319-
- The components are integrated in the circuit board for the selector mechanism function unit and cannot be replaced individually.
- Checking. Refer to the Vehicle Diagnostic Tester.
- Shift Mechanism, Removing and Installing. Refer to SHIFT MECHANISM, REMOVING AND INSTALLING .
