Lane Change Assistance Control Module, Lane Change Assistance Control Module 2, Burglary Protection Control Module 5, High-Mounted Brake Lamp Bulb, Parking Heater Radio Receiver, 12 V Socket 3
J769
Lane Change Assistance Control Module
J770
Lane Change Assistance Control Module 2
J1195
Burglary Protection Control Module 5
M25
High-Mounted Brake Lamp Bulb
R64
Parking Heater Radio Receiver
T2br
2-Pin Connector, Black
T2iv
2-Pin Connector, Black
T2iw
2-Pin Connector, Black
T3cl
3-Pin Connector, Naturally Cloudy
T6bb
6-Pin Connector, Black
T6bi
6-Pin Connector, Blue
T8x
8-Pin Connector, Black
T8y
8-Pin Connector, Black
THKM
Coupling Point on Rear Lid, Center
U19
12 V Socket 3
333
Ground Connection 5 (in Rear Wiring Harness)
*
Refer to Applicable Wiring Diagram for Auxiliary Coolant Heater
*2
Refer to Applicable Wiring Diagram for Sockets
*3
Refer to Applicable Telephone Systems Wiring Diagram
*4
Refer to Applicable Tail Lamp Wiring Diagram
*5
Refer to Applicable Lane Change Assistance Wiring Diagram
