Overview - Windshield Projection (Head-Up Display)

Fig 1: Exploded View Of Windshield Projection (Head-Up Display)

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

1. Windshield Projection Head Up Display Control Module -J898-
   • Removing and Installing. Refer to WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE, REMOVING AND INSTALLING .
2. Bolt
   • 1.5 Nm
   • Quantity: 3
3. Crossmember
   • Removing and installing. Refer to INSTRUMENT PANEL CROSSMEMBER, REMOVING AND INSTALLING .
