Striker, Removing And Installing: Installing

NOTE:

A striker with a curve must be installed.

-- Place the striker -1- with the curve facing inward on the B-pillar -3-. Tighten the bolts -2-.

Fig 1: Identifying Hood Catch

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Adjust the striker. Refer to STRIKER, ADJUSTING .
