Overview - Radio, Rcd 310: Notes
WARNING: This page is about a different car, the 2018 Volkswagen Jetta, 2017 Volkswagen Jetta, 2016 Volkswagen Jetta, and 2015 Volkswagen Jetta. However, it is still accessible from the selected car via links, so may be relevant.
Familiarity with the function and operation is needed if there are customer concerns. Refer to the appropriate information..
The RCD 310 radio system offers the following features:
- 4 speaker channels, each with 20 W
- CD player
- Monochrome display
- Connection for an external CD Changer -R41-
- Connection for Multimedia System Control Module -J650-
- External Audio Source Connection -R199-
- UHV Low (stereo input)
- Connection for external sound amplifier (Amplifier -R12-)
- Integrated optional DAB tuner
- Convenience coding
- Optional support for the multifunction steering wheel
- OPS (optical parking system) on the radio display
- Air Conditioning (A/C) information shown in the radio display
It is not possible to play the following CD formats:
- CD with 8 cm diameter
- "Mix CDs" (CDs containing files and audio files)
The RCD 310 is equipped with On Board Diagnostic (OBD).
NOTE:
OBD, Vehicle Diagnostic Tester.
