Left And Right Front Level Control System Sensor G78/G289, Removing And Installing: Removing
WARNING: This page is about a different car, the 2023 Volkswagen ID.4. However, it is still accessible from the selected car via links, so may be relevant.
The Left Front Level Control System Sensor -G78- and the Right Front Level Control System Sensor -G289- will be called front level control system sensor in the information that follows.
The following information describes the removing and installing on the left side of the vehicle as an example.
-- Remove the front body acceleration sensor. Refer to LEFT AND RIGHT FRONT BODY ACCELERATION SENSOR G341/G342, REMOVING AND INSTALLING .
-- Remove the control arm stone chip protection. Refer to Control Arm Stone Chip Protection, Removing and Installing .
-- Disconnect the connector -2-.
-- Remove the nuts -2-.
-- Unclip the wiring harness -3- from the bracket -1-.
-- Remove the bracket -1- using the front level control system sensor.
