Engine Compartment, Right
- 1 - Right LED headlamp power output module 1 -A27-
- 1 - Right front headlamp -MX2-
- 1 - Right headlamp beam adjustment motor -V49-
- 1 - Right headlamp power output module -J668-
- 1 - Right light control module -J1023-
- 2 - Refrigerant cut-off valve 5 -N643-
- 3 - A/C pressure/temperature sensor -G395-
- 3 - Refrigerant circuit pressure sensor -G805-
- 4 - Engine coolant level sensor -G32-
- 5 - Windshield defogger -Z2-
- 6 - Air quality sensor -G238-
- 7 - High voltage heater (PTC) control module -J848-
- 7 - High voltage heater (PTC) -Z115-
- 8 - A/C engine coolant temperature sensor -G110-
- 9 - Coolant change-over valve 1-N632-
- 10 - Temperature sensor before charger -G931-
- 11 - Right front ABS wheel speed sensor -G45-
- 12 - Right front brake pad wear sensor -G35-
- 13 - Hood contact switch -F387-
- 14 - AC pressure/temperature sensor 3 -G827-
- 15 - A/C pressure/temperature sensor 4 -G828-
- 16 - Passenger side front airbag crash sensor -G284-
- 17 - A/C pressure/temperature sensor 5 -G829-
- 656 - Ground connection on right headlamp
- 685 - Ground connection 1 on right front longitudinal member
- 778 - High voltage heating (PTC) ground connection
