Left/Right Effects Speaker -R209- / -R210-, Removing And Installing, BOSE: Notes

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2018 Audi S6, 2018 Audi A6 Quattro, 2018 Audi A6, 2017 Audi S6, and 2017 Audi A6 Quattro. However, it is still accessible from the selected car via links, so may be relevant.

Special tools and workshop equipment required

Torque Screwdriver :VAG1624

The Left Effects Speaker -R209- -1- / Right Effects Speaker -R210- -2- are located in the rear shelf on the left and right sides. The Effects Speakers are attached to the speaker trim.
