Vehicle Front Right View

  1. 672  - Ground connection 2 on left front longitudinal member
    • Tightening Specification 20 Nm
  2. 685  - Ground connection 1 on right front longitudinal member
    • Tightening Specification 9 Nm
G12709759Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
