Door Lock Control Switch

WARNING: This page is about a different car, the 2007 Mercury Mariner and 2007 Ford Escape. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: Escape shown, Mariner similar. LH side shown, RH side similar.

Fig 1: Exploded View Of Door Lock Control Switch

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	14A564	Window control switch bezel
2	14540	Window control switch

All vehicles

Remove the front door trim panel. For additional information, refer to INTERIOR TRIM AND ORNAMENTATION article.

Mariner

Remove the 3 screws and the front door trim panel arm rest.

All vehicles

Release the bezel retaining clip from the door trim panel.
Release the locking clips and remove the window control switch.
To install, reverse the removal procedure.
