Wheel Speed Sensor - Rear, FWD: Notes

WARNING: This page is about a different car, the 2005 Mercury Montego, 2005 Ford Freestyle, and 2005 Ford Five Hundred. However, it is still accessible from the selected car via links, so may be relevant.
NOTE: LH side shown, RH side similar.
Fig 1: Identifying Components Of Wheel Speed Sensor - Rear, FWD
G03988530Courtesy of FORD MOTOR CO.
