Heated Seat Module - Front Seat: Notes

WARNING: This page is about a different car, the 2010 Lincoln Town Car. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Exploded View Of Front Seat Heated Seat Module

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	-	Front passenger door
2	-	Electrical connector (part of 14A005)
3	-	Retainer
4	14C724	Heated seat module
