High Mounted Stoplamp: Notes

WARNING: This page is about a different car, the 2008 Ford RV Cutaway, 2008 Ford Econoline, 2008 Ford E450 Super Duty, and 2008 Ford Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Exploded View Of High Mounted Stoplamp
GF0012923Courtesy of FORD MOTOR CO.
Item Part Number Description
1 55927 Cargo lamp lens screws (2 required)
2 13K707 Cargo lamp lens
3 55928 Cargo lamp screws (2 required)
4 13K706 Cargo lamp assembly
5 - High mounted stoplamp bulb sockets (part of 13A613)
6 55998 High mounted stoplamp screws (2 required)
7 13A613 High mounted stoplamp
