Instrument Cluster Control Module -J285- / Anti-theft immobilizer control module -J362-







Control modules in front part of vehicle

Instrument Cluster Control Module -J285- / Anti-theft immobilizer control module -J362-




Pin Arrangements:




36-pin connector -T36- on wiring harness:
