SUBFRAME Assembly Overview

NOTE:

The illustration shows a right door hinge. The left door hinge is identical.

Fig 1: Identifying Subframe Assembly
GWWN57-10210Courtesy of AUDI OF AMERICA, LLC
  1. Door
  2. Release cable
    • from the internal mechanism to the door lock
  3. Cover caps for assembly opening
    • Quantity: 2
  4. Subframe
  5. Door lock
  6. Bolt
    • Quantity: 2
    • 20 Nm
  7. Bolt
    • Quantity: 10
    • 8 Nm
  8. Wiring harness
    • To the door lock
  9. Window Regulator Motor
  10. Window regulator
    • Is a component of the subframe
  11. Bolt
  12. Speaker
  13. Connector
    • For the A-pillar wiring harness.
  14. Wiring harness
    • To the exterior rearview mirror
