Vehicle Alignment Procedure Overview

Vehicle Alignment Procedure Overview

Observe the following work sequence!

- Pay attention to notes on wheel alignment device

Measuring Procedure






1 If steering wheel is crooked at end of alignment procedure, it must be straightened. Then perform basic setting for Steering Angle Sensor (G85) using Vehicle Diagnosis, Testing and Information System (VAS 5051).
