Tightening Specifications

Tightening Specifications






Engine Mount Bolts





1 40 Nm + 90° (1/4) additional turn 1
2 20 Nm + 90° (1/4) additional turn 1
3 60 Nm + 90° (1/4) additional turn 1

• 1 Always replace

Transmission Mount Bolts





A 40 Nm + 90° (1/4) additional turn 1
B 60 Nm + 90° (1/4) additional turn 1

• 1 Always replace

Pendulum Support Bolts





• Secure the pendulum support to the transmission first and then to the subframe.

A Strength category 8.8 = 40 Nm + 90° (1/4) additional turn 1
A Strength category 10.9 = 50 Nm + 90° (1/4) additional turn 1
B 100 Nm + 90° (1/4) additional turn 1

Removing: first remove the bolt - B -, then the bolts - A -.

Installing: first install the bolts - A -, then the bolt - B -.

• 1 Always replace
