A/C System Specifications
CAUTION:
When discharging air conditioning system, use only approved refrigerant recovery/recycling equipment. Make every attempt to avoid discharging refrigerant into the atmosphere.
SPECIFICATIONS
| Application | Specification | |||
|---|---|---|---|---|
| System Type | Cycling Clutch | |||
| Compressor Type | ||||
| Diesel | Sankyo 5-Cyl. | |||
| Gas | York 2-Cyl. | |||
| R-12 Capacity | 32-35 oz. | |||
| Oil Capacity | ||||
| Gas (York SC-209 Compressor) | 8 oz. | |||
| Diesel (Sankyo SD-508 Compressor) | 10 oz. | |||
| A/C Belt Deflection | (1) 3/16" | |||
| Normal Operating Pressures | ||||
| Low Side | 14-30 psi | |||
| High Side | 150-270 psi | |||
|
||||
