Components [10/2022 - ]
Fig 1: Engine Coolant Temperature Sensor Replacement Components [10/2022 - ]
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout
Description
Callout
Description
*A
except Mexico Models
-
-
*1
ENGINE COOLANT TEMPERATURE SENSOR
*2
NO. 2 ENGINE COOLANT TEMPERATURE SENSOR
•
Non-reusable part
-
-
