Components [04/2018 -]

Fig 1: VSC OFF Switch Replacement Components
GTY842879Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 COWL SIDE TRIM SUB-ASSEMBLY LH *2 FRONT DOOR OPENING TRIM WEATHERSTRIP LH
*3 FRONT DOOR SCUFF PLATE LH *4 HOOD LOCK CONTROL LEVER SUB-ASSEMBLY
*5 INSTRUMENT SIDE PANEL LH *6 NO. 1 INSTRUMENT PANEL SUB-ASSEMBLY
*7 NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY *8 VSC OFF SWITCH
