Alternators - NIPPONDENSO: Application
| Model |
Toyota Part No. |
| KC (1969-70) |
| |
Corolla 1100 Before 2/69 |
22010 |
| |
Corolla 1100 After 2/69 |
22011 |
| 3K-C (1970-73) |
| |
Corolla 1200 (1970-72) |
22011 |
| |
All Models W/3K-C Eng. (1973) |
24031 |
| 2T-C (1971-72) |
| |
Corolla (1971-72) |
25010 |
| |
Carina (1972) |
| |
All Models W/2T-C Eng. (1973) |
25010 |
| 8R-C (1969-71) |
| |
Corona Mk II |
33010 & 33030 |
| |
Hi-Lux |
22011, 31031 & 31032 |
| |
Corona & Celica |
33011 |
| 3R-B (1965-67) |
| |
1900 Sedan |
21011 |
| |
Corona & Crown |
| |
|
Before Eng. 3R 479894 |
21010 |
| |
|
After Eng. 3R 479894 |
21011 |
| Stout Pickup |
| |
Before Eng. 3R 590915 |
40010 |
| |
After Eng. 3R 590915 |
40011 |
| 3R-C (1968-70) |
| |
Corona & Hi Lux |
| |
|
Before 6/68 |
21011 |
| |
|
After 6/68 |
40060 |
| 18R-C (1972-73) |
| |
Corona & Celica (1972) |
33011 |
| |
Corona Mk II (1972) |
33030 |
| |
Hi-Lux (1972) |
31032 |
| |
All 1973 18R-C Eng |
33030 |
| M (1965-68) |
| |
Crown Before 11/68 |
41010 |
| 2M (1968-71) |
| |
Crown |
| |
|
After 11/68 |
41011 |
| |
|
After 9/69 |
41012 |
| 4M (1971-73) |
| |
Crown (1971-72) |
41032 |
| |
Corona (1971-72) |
41032 |
| |
All 4M Eng. (1973) |
45020 |
| F (1965-73) |
| |
From Eng. F224280 |
60021 |
| |
From Eng. F243298 |
60031 |
| |
From Eng. F270964 |
60032 |
| |
From 1/71 |
60033 |
| |
All F Eng. (1973) |
60040 |
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
