DTC B1125: Clutch / Shift Switch Malfunction
>>
Circuit Diagram
>>
M/T Model
April 5, 2026:
LEMON Manuals is launched!
Read the announcement.
M/T Model
Fig 1: Clutch / Shift Switch Malfunction Circuit Diagram (M/T Model)
Courtesy of SUZUKI OF AMERICA CORP.
Courtesy of SUZUKI OF AMERICA CORP.
