Reassembling Note for Wiring Harness
>>
Around Fuel Tank
April 5, 2026:
LEMON Manuals is launched!
Read the announcement.
Around Fuel Tank
Fig 1: Identifying Wiring Harness Clips (Around Rear End Door)
Courtesy of SUZUKI OF AMERICA CORP.
Courtesy of SUZUKI OF AMERICA CORP.
