Clutch Master Cylinder Removal and Installation: Removal

Clean around brake master cylinder reservoir cap and take out fluid with syringe or such from brake master cylinder reservoir.
Disconnect clutch fluid pipe (4) from clutch master cylinder (1). See CLUTCH FLUID PIPE REMOVAL AND INSTALLATION .
Disconnect clutch reservoir hose (2).
Remove push rod from clutch pedal, and then remove clutch master cylinder.

Fig 1: Identifying Clutch Fluid Pipe For Clutch Master Cylinder
Courtesy of SUZUKI OF AMERICA CORP.
