Thermostat Removal and Installation: Removal

WARNING: This page is about a different car, the 2011 Suzuki SX4. However, it is still accessible from the selected car via links, so may be relevant.

Drain coolant, see Cooling System Draining .
Remove front bumper. See FRONT BUMPER AND REAR BUMPER COMPONENTS
Remove engine wire harness bracket (1).

Fig 1: Identifying Engine Wire Harness Bracket
Courtesy of SUZUKI OF AMERICA CORP.
Disconnect radiator outlet hose (1) from thermostat cap (2).
Remove thermostat cap (2) from water pump (3).

Fig 2: Removing Thermostat Cap From Water Pump
Courtesy of SUZUKI OF AMERICA CORP.
Remove thermostat (1) from water pump (2).

Fig 3: Removing Thermostat From Water Pump
Courtesy of SUZUKI OF AMERICA CORP.
