Individual Circuit Fuse Box No. 1
WARNING: This page is about a different car, the 2011 Suzuki SX4. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of SUZUKI OF AMERICA CORP. FUSE BOX NO. 1 RELAY IDENTIFICATION
| RELAY DESCRIPTION |
| Cooling Fan Relay 1 |
| Cooling Fan Relay 2 |
| Cooling Fan Relay 3 |
| Starting Motor Relay |
| Main Relay |
| Throttle Actuator Control Relay |
| Fuel Pump Relay |
| Front Fog Light Relay |
| A/C Compressor Relay |
| Condenser Cooling Fan Relay |
| CVT Relay |
