Ignition Switch Removal and Installation: Removal

WARNING: This page is about a different car, the 2011 Suzuki SX4. However, it is still accessible from the selected car via links, so may be relevant.

Disconnect negative cable at battery.
Confirm that ignition key is removed.
Remove dash side trim (4) and steering column hole cover (1).
Turn steering wheel to remove steering column cover screws (3) and then remove steering column covers (2).

Fig 1: Removing Dash Side Trim And Steering Column Hole Cover
Courtesy of SUZUKI OF AMERICA CORP.
Remove steering column mounting nuts referring to Step 8) under "Removal" of STEERING COLUMN REMOVAL AND INSTALLATION .
Disconnect couplers (1) from ignition switch (2).
Remove ignition switch (2) from key cylinder (3).

Fig 2: Removing Ignition Switch From Key Cylinder
Courtesy of SUZUKI OF AMERICA CORP.
