Description of Clutch/Brake Functions
WARNING: This page is about a different variant/trim than selected.
| Part Name | Function |
|---|---|
| Overdrive clutch | Meshes overdrive carrier and overdrive sun gear. |
| Overdrive brake | Fixes overdrive sun gear. |
| Overdrive one-way clutch | Meshes overdrive carrier and overdrive sun gear only when driven by engine. |
| Forward clutch | Meshes input shaft and intermediate shaft. |
| Direct clutch | Meshes input shaft with front sun gear and rear sun gear. |
| Second coast brake | Fixes front sun gear and rear sun gear. |
| Second brake | Fixes outer race of one-way clutch No. 1, to prevent front sun gear and rear sun gear from turning counterclockwise (reverse direction of engine input rotation direction). |
| Reverse brake | Fixes front planetary carrier. |
| One-way clutch No. 1 | Prevents front sun gear and rear sun gear from turning counterclockwise only when second brake is at work. |
| One-way clutch No. 2 | Prevents front planetary - carrier from turning counterclockwise. |
