Reference Waveform No. 2
WARNING: This page is about a different variant/trim than selected.
TCC pressure control solenoid valve signal at engine idling.
| Measurement terminal |
CH1: "E92-5" to "E92-1" |
| Oscilloscope setting |
CH1: 5 V/DIV
Time: 2 ms/DIV |
| Measurement condition |
- After warmed up to normal operating temperature
- Engine at specified idle speed with "P" range
|
Courtesy of SUZUKI OF AMERICA CORP.
