Front Seat Belt Buckle Replacement

WARNING: This page is about a different car, the 2007 Suzuki XL7. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Front Seat Belt Buckle & Bolt

Courtesy of SUZUKI OF AMERICA CORP.

CALLOUT COMPONENT NAME

Callout	Component Name
1	Front Seat Belt Buckle Bolt (Qty: 1) CAUTION: Refer to FASTENER NOTICE . Tightening torque 45 N.m (33 lb ft)
2	Front Seat Belt Buckle Disconnect the electrical connector under the seat. Slide the buckle assembly upwards and out from between the seat cushion and the seat cushion inner trim panel.
