Ambient Air Temperature Sensor Replacement
WARNING: This page is about a different car, the 2007 Suzuki XL7. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of SUZUKI OF AMERICA CORP. TEMPERATURE SENSOR REFERENCE TABLE
| Callout |
Component Name |
| 1 |
Ambient Air Temperature Sensor Retainer |
| 2 |
Ambient Air Temperature Sensor
Tip:
Disconnect the electrical connector. |
