Brake Booster: Inspection: Operation

With engine stopped, change vacuum to atmospheric pressure by depressing brake pedal several times. Then with brake pedal fully depressed, start engine and when vacuum pressure reaches the standard, make sure that clearance between brake pedal and floor panel decreases.

Fig 1: Inspecting Brake Booster
G06442672Courtesy of SUZUKI OF AMERICA CORP.
