SDT Checking System: Description

WARNING: This page is about a different car, the 2011 Suzuki Equator. However, it is still accessible from the selected car via links, so may be relevant.

When SDT is connected with a data link connector equipped on the vehicle side, it will communicate with the control unit equipped in the vehicle and then enable various kinds of diagnostic tests.

Fig 1: Identifying Hood Release Handle And Data Link Connector
Courtesy of SUZUKI OF AMERICA CORP.
Refer to SDT Operation Manual for more information.
