Reassembling Note for Wiring Harness
>>
Around Strut
>>
Left side
April 5, 2026:
LEMON Manuals is launched!
Read the announcement.
Left side
Fig 1: Identifying Engine Harness Connector - Strut (Left Side)
Courtesy of SUZUKI OF AMERICA CORP.
Courtesy of SUZUKI OF AMERICA CORP.
