Sunroof System: Adjustment: Notes

Inspect then measure the gap and height difference between the glass lid assembly and roof panel; compare to specifications. Determine which procedure to follow based on results of measurements.

Fig 1: Identifying Gap And Height Difference Between Glass Lid Assembly And Roof Panel

Courtesy of SUZUKI OF AMERICA CORP.
