Battery: Service and Repair
Battery Removal and InstallationWARNING:
- Hydrogen gas is produced by battery. A flame or spark near battery may cause the gas ignites.
- Battery fluid is highly acidic. Avoid spilling electrolyte on clothing or other fabric. Any spilled electrolyte should be flushed with large quantity of water and cleaned immediately.
Removal
1. Disconnect negative (-) cable (3).
2. Disconnect positive (+) cable (2).
3. Remove retainer (4).
4. Remove battery (1).
Installation
1. Reverse removal procedure.
2. Tighten battery cables securely.
3. After installation, initialize electrical devices as needed referring to General Precautions.
