Inflatable Restraint Steering Wheel Module Coil X3
Connector Part Information
OEM: 15393421
Service: 88987853
Description: 4-Way F Micro-Pack 064 Series (YE)
Terminal Part Information
Terminal/Tray: 12177007/19
Core/Insulation Crimp: E/2
Release Tool/Test Probe: 12180559-1/J-35616-64B (L-BU)
CONNECTOR PINOUTS REFERENCE
| Pin | Wire | Circuit | Function |
|---|---|---|---|
| 1 | 0.35 BN | 3020 | Steering Wheel Module - Stage 1 - Low Control |
| 2 | 0.35 TN | 3021 | Steering Wheel Module - Stage 1 - High Control |
| 3 | 0.35 PK | 3022 | Steering Wheel Module - Stage 2 - Low Control |
| 4 | 0.35 WH | 3023 | Steering Wheel Module - Stage 2 - High Control |
