Collision Diagnosis: For Frontal Collision
Collision Diagnosis: For Side And Rollover CollisionCheck the SRS components using the following table.
- After the work is completed, perform self-diagnosis to check that no malfunction is detected. Refer to [SRS Operation Check]. Component Tests and General Diagnostics
SRS INSPECTION (FOR FRONTAL COLLISION)
SRS Inspection (For Frontal Collision):
