Roof Console Replacement

Fig 1: Identifying Roof Console Components

Courtesy of SUZUKI OF AMERICA CORP.

ROOF CONSOLE COMPONENTS REFERENCE COMPONENTS REFERENCE

Callout	Component Name
1	Front Overhead Console Screw (Qty: 2) CAUTION: Refer to FASTENER NOTICE . Tightening torque 2 N.m (18 lb in)
2	Front Overhead Console Assembly Tip: Disconnect electrical connector.
3	Front Overhead Console Retainer (Qty: 2)
