Installation Procedure

Fig 1: Seat Belt Height Adjuster

Courtesy of GENERAL MOTORS CORP.

NOTE: Refer to Fastener Notice .

Install the seat belt height adjuster (1) with the bolts (2).
Tighten: Tighten the seat belt height adjuster bolts to 27 N.m (20 lb ft).
Install the upper center pillar trim panel. Refer to Center Pillar Upper Trim Panel Replacement .
