Fig 1: Instrument Cluster Power and Ground, Ambient Temperature, Engine Temperature, Fuel, Speed Gages
Courtesy of GENERAL MOTORS CORP.
Fig 2: Turn, High Beam, Fog Indicators, Instrument Cluster Illumination
