Installation Procedure

    Fig 1: Channel Molding
    GM1720604Courtesy of GENERAL MOTORS CORP.
  1. Install the channel molding onto the door trim panel.
  2. Bend the retaining tabs to secure the channel molding to the door trim panel.
  3. Install the door trim panel. Refer to Front Side Door Trim Panel Replacement .
