Input Shaft Speed Sensor Removal and Installation: Removal

WARNING: This page is about a different variant/trim than selected.
  1. Remove battery and battery tray.
  2. Disconnect input shaft speed sensor connector (2).
  3. Remove input shaft speed sensor (1) by removing its bolt.
    Fig 1: Identifying Input Shaft Speed Sensor
    G04847780Courtesy of SUZUKI OF AMERICA CORP.
