Input Shaft Speed Sensor Removal and Installation: Installation

Reference:  INPUT SHAFT SPEED SENSOR INSPECTION

1. Apply A/T fluid to new input shaft speed sensor O-ring.
2. Install input shaft speed sensor (1) to A/T case and tighten bolt to specified torque.

   Tightening torque

   Input shaft speed sensor bolt a: 5.5 N.m (0.55 kg-m, 4.0 lb-ft)

3. Connect input shaft speed sensor connector (2) to input shaft speed sensor (1).
   Fig 1: Identifying Input Shaft Speed Sensor Connector

   Courtesy of SUZUKI OF AMERICA CORP.
4. Install battery tray and battery.
