Instrument Cluster Trim Panel Removal and Installation: Installation

WARNING: This page is about a different car, the 2005 Suzuki Reno and 2005 Suzuki Forenza. However, it is still accessible from the selected car via links, so may be relevant.
  1. Connect the electrical connectors.
  2. Install the instrument cluster trim panel with the screws.
    Fig 1: Installing Instrument Cluster Trim Panel
    G04104396Courtesy of SUZUKI OF AMERICA CORP.
